Specifications

Unity machine parameter

Drilling depth

200m

Maximum open hole caliber

300mm

Drill rod caliber

50mm

Drilling angle

90°～75°

Drill weight (No include power)

975kg

Unity machine dimensions

2.5×1×1.3  2.5×0.9×1.3m

Spindle

spindle speed

64、128、287、557r/min

Spindle stroke

 450mm

Hoist

Max.single line hoisting capacity

2400kg

Single line lifting speed

17、35、75、151r/min

Tightrope caliber

12.5mm

Tightrope cubic measure

35m

Hug floodgate caliber

260mm

Hug folldgate belt width

70mm

Mud pump

Type

Horizontal single urn twin-action

Displacement

170L/min

Diesle engine

S1110 Model  18HP

 Electric motor

Y160M—4 11kw 1440r/min

 Maximum pressure

3Mpa

Work pressure

1.5Mpa

 Water inlet caliber

40mm

 Water to exit caliber

30mm

Triangle conveyer belt

B1728mm
