The serial number

The name of the

parameter

1

Max drill depth

400m

2

Borehole diameter

4”-18”

3

Power head Torque

 KN

8900NM

4

Pull up-Pull down cylinder

T

Pull up: 25T

Pull down:12 T

5

Drilling Power:

 the diesel engine on deck, 132Kw，

6

Tool winch:

1T

7

Air compressor

 new type

Pressure

290PSI

flow

1024CFM

8

Foam Pump:

Pressure

40 bar

flow

42L/min

9

Mud pump:

Pressure

25 bar

flow

900L/min
